Panorama 1 Spot Light 10watt LED White Sensor

Product Description

The Panorama 10W LED Security Light with PIR Sensor offers a sleek, modern design paired with reliable performance for outdoor security. Finished in crisp white, this compact spotlight features an adjustable lamp head and integrated PIR motion sensor, ensuring bright, energy-efficient illumination exactly where it’s needed. With multiple colour temperature options and weather-resistant construction, it’s a versatile choice for enhancing safety around residential or commercial spaces.

Features

• Modern, compact design with adjustable lamp head

• Integrated PIR motion sensor for improved security

• Bright and efficient 10W LED with Tri-Colour selection (3000K / 4000K / 5000K)

• Wide 75° beam angle for effective coverage

• Flicker-free, non-dimmable operation

• Weather-resistant housing with IP65 protection

• Easy surface-mount installation

• Backed by a 5-year warranty

Specifications

Key Information

• Input Power: 10W

• Lumen Output: 790 / 880 / 910 lm

• Fitting Colour: White

• Installation: Surface mount

• Dimming Options: Non-dimmable

• IP Rating: IP65

• Warranty: 5 years

PIR Sensor

• Detection Distance: 1 – 5m

• Detection Range: 110°

• Ambient Light Range: 10 – 300 lux

• Time Delay: 2 seconds – 10 minutes

• Manual Override: Available (via power switch reset)

Photometric

• Efficacy: 79 / 88 / 91 lm/W

• LED Type: SMD

• CCT: 3000K / 4000K / 5000K (Tri-Colour selectable)

• CRI: >80

• Beam Angle: 75°

Electrical

• Input Supply: 220–240V, 50/60Hz

• Driver Output Voltage: 68V DC

• Power Factor: >0.9

• LED Input Current (nominal): 130mA

• Lifetime: 36,000 hrs (L70 @ Ta25°C)

• Electrical Classification: Class II

Construction

• Housing: Polycarbonate

• Diffuser: Polycarbonate (opal)

• Adjustable Angle: 0–360°

• Fixings: Mounting plate

• Connection: Terminal block

• Weight: 0.34kg

• Dimensions: Ø107 × 189mm

• Operating Temperature: -20°C to +45°C
