Panorama 1 Spot Light 10watt LED White Sensor

Product Description

10W white finish single
lamp LED security light
with sensor
PANORAMA is series of modern
look PC LED security lights with
adjustable lamp and PIR sensor

KEY INFORMATION

Lumen Output 790 / 910 / 880lm
Input Power 10W
Hole Cutout Size N/A
Install SURFACE MOUNT
Dimming Options Non-Dimmable
Fitting Colour WHITE
Warranty 5yr
IP Rating IP65
IK Rating N/A
IC Rating N/A
Rebate Scheme Approvals N/A

PIR SENSOR

Detection Distance 1 to 5m
Detection Range 110°
Ambient Light 10 to 300Lux
Time Delay 2s to 10mins
Manual Override Turning the light off then turning on
within 3 seconds

PHOTOMETRIC

Efficacy 79 / 91 / 88lm/W
LED SMD
CCT 3000 / 4000 / 5000K
CRI >80
Beam Angle 75°

ELECTRICAL

Supply Input 220-240V, 50/60Hz
Driver Output Voltage 68V DC
Power Factor >0.9
LED Input Current (nominal) 130mA
Useful life @Ta25° (L70) 36,000hr
CONSTRUCTION
Housing Polycarbonate
Optics Polycarbonate Diffuser
Adjustable Angle 0-360°
Fixings/Hardware Mounting Plate
Connection Type Terminal Block
Total Weight 0.34kg
Dimensions Ø107 x 189mm
Operating Ambient Temp. -20 to 45°C
Electrical Classification Class 2
